WIRELOCK Resin 2000cc

The WIRELOCK Resin 2000cc provides a safe and efficient method for terminating wire ropes using spelter sockets. Unlike traditional molten metal methods, WIRELOCK® is a two-part cold-applied resin system that simplifies the socketing process, making it ideal for on-site applications.

This 2000 cc kit is suitable for use with Crosby 416, 417, 427, and 517 series spelter sockets. It delivers superior fatigue resistance and long-term performance in both static and dynamic lifting systems.

Key Features:

• 100% termination efficiency for wire rope assemblies

• Cold-applied resin system eliminates the need for molten metal

• Safe and easy to use on-site in various weather conditions

• Operating temperature range: -65°F to +240°F (-54°C to +116°C)

• Pouring temperature range: 48°F to 110°F (9°C to 43°C) without booster packs

• Booster packs available for lower temperature applications

• Gel time: Approximately 20 minutes at 65°F (18°C)

• Shelf life: 18 months when stored properly

• Color change indicator ensures proper mixing

• Approvals: ABS, DNV, Lloyd’s Register, ISO 17558, DNV-OS-E304, OSHA 1926.1431/1926.1501, CE Certified

Applications:

• Crane ropes and boom pendants

• Winches and lifting straps

• Mast stays and suspended roofs

• Bridges and structural applications

• Mining and offshore mooring systems
