The Floyd Gauge Stainless Steel Pressure Gauge 0–1600 kPa is a robust industrial pressure gauge designed for reliable pressure monitoring across process equipment, machinery and general industrial applications.
Featuring a large 100mm dial, this direct-mount pressure gauge provides clear, easy-to-read pressure indication. The gauge combines a durable 304 stainless steel case with a 316 stainless steel process connection, providing excellent corrosion resistance and dependable performance in demanding environments.
With a 0–1600 kPa pressure range and 1/2" NPT bottom-entry connection, the gauge is designed for straightforward direct installation into compatible pipework, equipment and process systems. Its dry-case construction provides a practical solution for general industrial pressure measurement.
Key Features
- 0–1600 kPa pressure range
- Large 100mm dial
- Direct mount configuration
- 1/2" NPT bottom entry
- Durable 304 stainless steel case
- 316 stainless steel process connection
- Dry case
- Clear and easy-to-read pressure scale
- Suitable for industrial, process and equipment pressure monitoring
Specifications
Brand: Floyd Gauge
Product Type: Stainless Steel Pressure Gauge
Product Code: PBX100AS16-1/2
Pressure Range: 0–1600 kPa
Dial Diameter: 100mm
Mounting: Direct Mount
Connection Size: 1/2" NPT
Connection Position: Bottom Entry
Case Material: 304 Stainless Steel
Connection Material: 316 Stainless Steel
Case Type: Dry
