The Floyd Stainless Steel Pressure Gauge 0–250 kPa is a heavy-duty industrial pressure gauge designed for reliable pressure measurement in process, equipment and general industrial applications.
Featuring a large 100mm dial, the gauge provides clear pressure indication and incorporates a durable 304 stainless steel case with a 316 stainless steel process connection for excellent corrosion resistance.
The 0–250 kPa pressure range, direct-mount configuration and 1/2" NPT bottom-entry connection allow straightforward installation into compatible pipework and equipment. The dry-case construction makes it a practical choice for general industrial pressure monitoring.
Key Features
-
Pressure range: 0–250 kPa
-
Large 100mm dial
-
Direct mount
-
1/2" NPT bottom entry
-
304 stainless steel case
-
316 stainless steel connection
-
Dry case
-
Heavy-duty industrial construction
-
Clear, easy-to-read pressure indication
Specifications
|
| Brand | Floyd Gauge |
| Product Code | PBX100AS11-1/2 |
| Pressure Range | 0–250 kPa |
| Dial Size | 100mm |
| Mounting | Direct Mount |
| Connection | 1/2" NPT |
| Connection Position | Bottom Entry |
| Case Material | 304 Stainless Steel |
| Connection Material | 316 Stainless Steel |
| Case Type | Dry |
